Specification |
ATV 50 |
ATV 90 |
ATV 100 |
|
ENGINE TYPE |
2 stroke Horizontal |
2 stroke Horizontal |
2 stroke Horizontal |
|
MAX. POWER |
3.1kw/7000rpm/min |
4.7kw/7000rpm/min |
5.2kw/6500r/min |
|
CYLINDER NO. |
1 |
1 |
1 |
|
BORE STROKE |
40X39.2 |
50X42 |
42X45 |
|
DISPLACEMENT |
49cc |
82cc |
95.6cc |
|
MAX. TORQUE |
4.4 N-m/5000rpm |
7.4N-m/4500rpm |
8.4N-m/4500rpm |
|
CARBURETOR |
Mikuni |
Mikuni |
Mikuni |
|
STARTING |
Electric/Kicker |
Electric/Kicker |
Electric/Kicker |
|
LUBRICATE |
Separated |
Separated |
Separated |
|
LUBR. CAPABILITY |
1 Liter |
1 Liter |
1 Liter |
|
SUSPENSION FRONT |
Double Wishbone |
Double Wishbone |
Double Wishbone |
|
SUSPENSION REAR |
Singnal Damper |
Singnal Damper |
Signal Damper |
|
BRAKE FRONT |
Drum |
Drum |
Drum |
|
BRAKE REAR |
Drum |
Drum, Disc (option) |
Drum, Disc (option) |
|
TIRE FRONT |
16x8-7 |
16x8-7 |
16x8-7 |
|
TIRE REAR |
16x8-7 |
18x9.5-8 |
18x9.5-8 |
|
TRANSMISSION |
Automatic |
Automatic |
Automatic |
|
(C.V.T. system) |
(C.V.T. system) |
(C.V.T. system) |
|
FUEL |
Unleaded Gasoline |
Unleaded Gasoline |
Unleaded Gasoline |
|
FUEL CAPABILITY |
5 liter |
5 liter |
5 liter |
|
OVERALL DIMENSION |
1380 x 870 x 770mm |
1380 x 870 x 770mm |
1380 x 870 x 770mm |
|
PACKAGE40'HQ (SET) |
66 |
66 |
66 |
|
WHEELBASE |
895 mm |
895 mm |
895 mm |
|
SEAT HEIGHT |
570 mm |
620 mm |
620 mm |
|
GROUND CLEARANCE |
80 mm |
123 mm |
123 mm |
|
DRY WEIGHT |
96 kgs |
106 kgs |
106 kgs |
|
MAX. LOAD |
80 kgs |
80 kgs |
80 kgs |
*
With EEC Homologation * |
